2024 Marin Rift Zone 1 29

The 2024 Marin Rift Zone 1 29 is a versatile full-suspension trail bike designed for riders who want confident handling, smooth suspension performance, and all-around trail capability. Built around Marin’s Series 3 aluminum frame and MultiTrac suspension platform, the Rift Zone 1 offers balanced geometry that excels on climbs while staying playful and stable on descents.

With 140mm of front and 130mm of rear suspension travel, 29” wheels for improved rollover, and modern trail-ready components, the Rift Zone 1 29 is ideal for everything from flow trails and technical singletrack to long days exploring new terrain. It’s a perfect entry into full-suspension riding without sacrificing performance or durability.

Features:

• Series 3 aluminum frame with modern trail geometry
• 140mm Front / 130mm rear suspension for balanced trail performance
• Marin MultiTrac suspension platform for efficient pedaling
• 29” wheels improve rollover and stability on rough terrain
• 1x drivetrain for simple, reliable shifting
• Hydraulic disc brakes provide strong stopping power
• Internal cable routing for a clean, modern look
• Trail-ready components built for durability and performance

Specifications:

• Frame: Series 3 6061 Aluminum, 29” Wheels, 130mm Travel, MultiTrac Suspension Platform, 141 Boost Spacing (upgradable to 148x12), 73mm Threaded BB w/ ISCG05 Tabs

• Fork: X-Fusion Slide Boost RC, 29", 140mm Travel, Compression and Rebound Adjustment, 44mm Offset

• Rear Shock: X-Fusion O2 Pro R, Custom Tune, 210x55mm, M8x25mm Hardware Top and Bottom

• Drivetrain: Shimano Deore 11 Speed

• Crankset: Marin Forged Alloy, Integrated Steel 32T Narrow Wide Chainring, Boost Spacing

• Cassette: Sunrace, 11-Speed, 11-51T, ED Black Wide-range cassette

• Brakes: Tektro HD-M280 Hydraulic Disc Brakes, 180mm Rotor F/R

• Wheel Size: 29"

• Tires: Vee Tire Co. Snap WCE 29x2.35", Top 40 Compound, GXE Core, 90 TPI, Tubeless Compatible

• Rims: Marin Aluminum Double Wall, 29mm Inner, Pinned Joint, Disc Specific, Tubeless Compatible

• Handlebar: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back

• Stem: Marin 3D Forged Alloy, 35mm

• Seatpost: Marin Alloy, 30.9mm
