Key upgrades over the DSX 1:
- Shimano Deore 6100 1x12 drivetrain
- Shimano hydraulic disc brakes
SERIES 3 & SERIES 2 FRAMES
The DSX FS, 2, and 1 feature a butted and formed Series 3 6061 aluminum frame with internal routing, 142x12mm thru-axles, flat mount disc brakes, and rack and fender eyelets.
The DSX (base) model utilizes a Series 2 6061 aluminum frame with internal cable routing, and rack and fender eyelets.
TIRE CLEARANCE
The DSX comes stock with 700x45mm tires, with room for 29x2.1” knobbies.
DISC BRAKES
The DSX features the latest flat mount disc brake standard for smooth, controlled stopping in all conditions with minimal maintenance.
DROPPER POST ROUTING
Dropper posts are quickly becoming standard fare for gravel racers and riders that spend significant time on rough surfaces, and the DSX features internal dropper post routing for easy upgrades.
GEOMETRY:
|
|
S |
M |
L |
XL |
|
A STACK |
544.4 |
572.5 |
600.6 |
628.7 |
|
B REACH |
380 |
405 |
420 |
435 |
|
C HEADTUBE ANGLE |
69.5° |
69.5° |
69.5° |
69.5° |
|
D HEADTUBE LENGTH |
120 |
150 |
180 |
210 |
|
E SEATTUBE ANGLE |
74° |
74° |
74° |
74° |
|
F SEATTUBE LENGTH |
430 |
480 |
520 |
558 |
|
G TOPTUBE EFFECTIVE |
536.1 |
569.2 |
592.2 |
615.3 |
|
H BB HEIGHT |
279.5 |
279.5 |
279.5 |
279.5 |
|
I BB DROP |
80 |
80 |
80 |
80 |
|
J CHAINSTAY |
425 |
425 |
425 |
425 |
|
K WHEELBASE |
1024.42 |
1060 |
1085.4 |
1110.9 |
|
L STANDOVER HEIGHT |
658.76 |
700.51 |
730.39 |
758.5 |
|
M FORK OFFSET |
50 |
50 |
50 |
50 |
|
SEATPOST DIAMETER |
27.2 |
27.2 |
27.2 |
27.2 |
|
HANDLEBAR WIDTH |
640 |
680 |
680 |
680 |
|
STEM LENGTH |
70 |
70 |
70 |
70 |
|
CRANK LENGTH |
170 |
170 |
175 |
175 |
All lengths in millimeters
Specs:
FRAME: Series 3 DSX, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
FORK: Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
RIMS: Marin Aluminum Double Wall, 21mm Inner, Disc Specific
HUB, REAR: Shimano Forged Aluminum, 142x12mm, Microspline, Centerlock, 32H
HUB, FRONT: Forged Aluminum, 100x12mm, Centerlock, 32H
SPOKE, NIPPLES: 14g Black Stainless Steel
TIRES: WTB Riddler, 700Cx45mm
DERAILLEUR, REAR: Shimano Deore 12-Speed
DERAILLEUR, FRONT: -
SHIFT LEVER: Shimano Deore 12-Speed
CRANKSET: Forged Aluminum, 42T Steel Narrow Wide Chainring
BOTTOM BRACKET: Sealed Outboard Bearing
CHAIN: KMC X12
CASSETTE: Shimano Deore 12-Speed, 10-51T
BRAKE, FRONT: Shimano MT201/UR300 Flat Mount Hydraulic Disc, 160mm Rotor
BRAKE, REAR: Shimano MT201/UR300 Flat Mount Hydraulic Disc, 160mm Rotor
BRAKE LEVERS: Shimao Hydraulic
HANDLEBAR: Marin MiniRiser
STEM: Marin 3D Forged Alloy
GRIPS: Marin MTB
HEADSET: FSA No.42 ACB, Sealed Cartridge Bearings, 1 1/8” x 1 1/2”
SEATPOST: Marin Alloy
SADDLE: Marin DSX
PEDALS: Commute Platform
EXTRAS: Bolt-On Thru-Axles F and R
Specifications, pricing, and availability are subject to change without notice.
